Mótar Gear Coscáin

Praghas fabhrach, seachadadh tapa, seirbhís thráthúil - Is é ANG do sholáthraí iontaofa mótar fearas coscáin, atá ardéifeachtúlachta, torann íseal, ardú teocht íseal, saol seirbhíse fada, srl.

Glaoigh Linn

Réamhrá Táirgí

Cé muid?

Déanann Hangzhou ANG Drive Co., Ltd speisialtóireacht i mótar leictreach, giarbhosca, fearas mótair, agus córas rialaithe ag forbairt, déantúsaíocht, rialú cáilíochta agus trádáil.

Cad a dhéanaimid?

1. leictritheoir AC

2. Electricmotor DC - amp scuabtha &; gan scuab

3. Mótar fearas coscáin

4. Giarbhosca péisteanna

5. Giarbhosca helical

Raon an mhótair fearas coscáin:

Cineál AC nó DC

Cumhacht 6w ~ 250kw

Voltas 110v 220v 380v, etc.

Minicíocht 50Hz 60Hz

Luas 1rpm ~ 3600rpm

Sonraí teicniúla mótar fearas coscáin:

TORADH SYNCHRONOUS SPEED=FREQUENCY 1500RPM=VOLTAGE 50HZ=380V

MIONSAMHAIL	CUMHACHT (KW)	SPEED (RPM)	REATHA (A)	CEI	CUMHACHT FACTOR	IST / IN	TST / TN	TMAX / TN	Statach coscán chasmhóiminte Níl níos lú ná N.m	Spreagadh voltas UF (V)	Nóiméad ofinertia GB²	NOISE dB (A)
YEJ-801-4	0.55kw	1390rpm	1.4	79	0.87	6.5	2.2	2.2	7.36	100	0.00866	0.2
YEJ-802-4	0.75kw	1390rpm	1.9	79.6	0.87	6.5	2.2	2.2	14.7	100	0.01073	0.2
YEJ-90S-4	1.1kw	1400rpm	2.7	81.4	0.87	6.5	2.2	2.2	14.7	100	0.01132	0.25
YEJ-90L-4	1.5kw	1400rpm	3.6	82.8	0.81	6.5	2.2	2.2	29.4	100	0.0143	0.25
YEJ-100L1-4	2.2kw	1430rpm	4.8	84.3	0.82	7	2.2	2.2	29.4	100	0.02733	0.3
YEJ-100L2-4	3kw	1430rpm	6.6	85.5	0.82	7	2.2	2.2	39.2	100	0.03506	0.3
YEJ-112M-4	4kw	1440rpm	8.6	86.6	0.82	7	2.2	2.2	73.6	170	0.04969	0.35
YEJ-132S-4	5.5kw	1440rpm	11.6	87.7	0.83	7	2.2	2.2	73.6	170	0.11584	0.4
YEJ-132M-4	7.5kw	1440rpm	14.6	88.7	0.85	7	2.2	2.2	147.2	170	0.15404	0.4
YEJ-160M-4	11kw	1460rpm	22.6	89.8	0.86	7	2.2	2.2	147.2	170	0.3986	0.5
YEJ-160L-4	15kw	1460rpm	29.3	90.6	0.86	7	2.2	2.2	215.8	170	0.68288	0.5
YEJ-180M-4	18.5kw	1470rpm	33.45	91.2	0.86	7	2.2	2.2	215.8	170	0.68667	0.6
YEJ-180L-4	22kw	1470rpm	42.35	91.6	0.86	7	2.2	2.2	294.3	170	0.7677	0.6
YEJ-200L-4	30kw	1475rpm	57.6	92.3	0.86	7	2.2	2.2	414.5	170	1.3963	0.7
YEJ-225S-4	37kw	1480rpm	69.8	92.7	0.86	7	2.2	2.2	441.5	170	2.158	0.8
YEJ-225M-4	45kw	1480rpm	84.5	93.1	0.86	7	2.2	2.2	14.7	170	2.463	0.8
